Model:1769-ECR
Module Type:Source Output
Operating Current:5 mA at 5.1 VDC
Weight:130 g (0.286 lb)
Enclosure Style:Open
Altitude:Up to 2000 m (6562 ft)
Bus Current Draw:5 mA at 5 volts DC
Backplane Current:1.4 Amps at 24 Volts
Power Consumption:33.6 Watts
The Allen-Bradley 1769-ECR A Source Output Module is specifically engineered to extend the functionality of your CompactLogix system by adding a reliable source output capability. Its compact design ensures seamless integration without compromising on performance.
This module, weighing 525 grams or 1.16 pounds, is built with an open-style enclosure, offering optimal airflow and cooling for enhanced reliability in industrial environments.
With its ability to draw a maximum of 5 milliamps at 5 volts DC from the bus, the 1769-ECR ensures efficient power consumption, making it ideal for applications requiring precise control over outputs. It supports up to 1.4 amps at 24 volts through the backplane, providing ample power for various output devices.
The Allen-Bradley brand guarantees robust quality and reliability, ensuring that your system operates smoothly under demanding conditions. This module is designed for durability, making it a long-term investment for your industrial automation needs.
Installation is straightforward, as it can be easily placed at the right end of your CompactLogix assembly. This strategic placement ensures optimal use of space and ease of integration within your existing setup.
