GE IS200TBTCH1C Thermocouple Input Terminal Board, 190 Characters

Part Number:IS200TBTCH1C

Manufacturer:General Electric Company USA, GE Industrial Systems

Series:Mark VIe

Model Type:Thermocouple Input

Number of DC-Type Connectors:Two

Compatibility:PTCC I/O Pack Inputs for Simplex Pack

System Application Type:Simplex

Analog Inputs Supported:T, S, K, J, E types

    The IS200TBTCH1C Thermocouple Input Terminal Board is part of the Mark VIe Series produced by General Electric. It is specifically designed to support multiple types of thermocouples including T, S, K, J, and E types, making it an indispensable component in precise temperature measurement systems. With two DC-type connectors and compatibility with PTCC I/O Pack Inputs for Simplex Pack, this board ensures seamless integration within a wide range of industrial control systems.

    This terminal board is constructed with high-quality materials to ensure durability and reliability under various environmental conditions. Its design includes two equally long lines of small silver capacitors alternating with rows of resistors positioned in the center, and a line of components labeled with the initial ‘L’ aligned on the right edge. These design elements enhance its functionality and robustness, ensuring consistent performance over time.

    For installation, refer to the technical documentation provided by General Electric, the GEH-6721G Mark VIe Control System Guide Volume II. This manual offers detailed instructions and guidance to help you integrate the IS200TBTCH1C into your existing system efficiently and effectively.

    Investing in the IS200TBTCH1C Thermocouple Input Terminal Board from General Electric means investing in precision, reliability, and durability. Whether for new installations or upgrades to existing systems, this board stands out as a superior choice for temperature measurement in industrial environments.
