Manufacturer:NACHI
Model Number:MFMA452D5V3
Type:Precision Ball Screw Actuator
Thread Diameter:5mm
Lead:2mm
Accuracy Grade:C5
Travel Stroke:Up to 500mm
Maximum Load Capacity:1000N
Operating Speed:Up to 5000mm/min
Life Expectancy:Up to 10,000km
Operating Temperature Range:-20°C to +80°C
Material:High-grade steel
The NACHI MFMA452D5V3 Linear Guide Module is a high-precision linear motion solution designed for demanding industrial environments. Its core feature is the use of steel balls within the guide way, ensuring smooth and accurate movement with minimal friction. This module is perfect for applications where precision and reliability are paramount, such as in robotics, CNC machines, and automated assembly lines.
The module’s robust construction includes a combination of steel and aluminum alloy materials, providing both strength and lightweight properties. The pre-drilled mounting holes are precisely aligned, making installation quick and straightforward. Additionally, the black oxide coating on the surface ensures durability and corrosion resistance.
With a travel length of 500mm and a load capacity of 15kN, this linear guide module offers exceptional performance and versatility. It is suitable for a wide range of applications and can operate efficiently in temperatures ranging from -20°C to +70°C. The life expectancy of up to 20,000km makes it a reliable choice for long-term projects.
Certified to CE and ISO9001 standards, the NACHI MFMA452D5V3 Linear Guide Module meets international quality and safety requirements. Its high precision class ensures consistent performance over time, making it an excellent choice for high-end industrial applications.
