Number of Channels:16
Rating per Channel:5A SPST
Operating Voltage:12VDC
Operating Current:1A
Relay Contact Rating:5A @ 24VDC, 3A @ 115VAC
Relay Type:SPST
Module Size:Compact 3U PXI form factor
Communication Interface:PXI Bus
Power Consumption:≤ 2W
Temperature Range:-40°C to +85°C
Relay Life Expectancy:Over 100 million operations
The PXI-2564 is specifically engineered for integration into advanced test and measurement systems, providing reliable switching capabilities across a wide range of voltages and currents.
Each of the 16 SPST channels supports a maximum current of 5A, ensuring that it can handle a broad spectrum of applications, from low-power electronics testing to high-current motor control.
Featuring a compact 3U PXI form factor, this relay module optimizes space utilization in your test bench setup, making it an ideal choice for both new and existing PXI-based systems.
With its robust design and ability to withstand extreme temperatures ranging from -40°C to +85°C, the PXI-2564 is suitable for deployment in harsh environments without compromising performance.
The PXI-2564 includes a PXI Bus interface for seamless communication with other PXI modules and accessories, facilitating easy integration into complex test and measurement configurations.
