Operating Voltage:120 VAC / 24 VDC
Current Rating:10 A @ 120 VAC, 25 A @ 24 VDC
Contact Type:SPDT (Single Pole, Double Throw)
Switching Capacity:10 A at 240 VAC, 10 A at 30 VDC
Operating Temperature:-20°C to +60°C
Insulation Resistance:≥ 100 MΩ at 500 VDC
Leakage Current:< 1 mA at 24 VDC
The Panasonic ZUEP14022B is engineered for demanding industrial environments, ensuring robust performance and reliability. Its compact design makes it suitable for space-constrained systems, while its high switching capacity supports a wide range of applications from automation to power management.
Featuring a durable silver-plated copper contact system, this relay module ensures long-lasting operation and minimal wear, even under heavy duty conditions. It is compatible with most PLCs and control panels, facilitating easy integration into existing systems.
With an operating voltage range from 12 to 24V DC, the ZUEP14022B is versatile enough for various industrial settings. Its SPDT configuration offers a single pole and double throw, providing flexibility in circuit control and switching operations.
This module is designed to withstand harsh industrial temperatures ranging from -20°C to +70°C, ensuring reliable operation across different climates and conditions. Its IP20 protection class safeguards against dust ingress, making it suitable for factory floors and other industrial environments.
In summary, the Panasonic ZUEP14022B is an essential component for industrial control systems, offering a combination of reliability, efficiency, and compatibility. Its robust construction and extensive feature set make it an ideal choice for engineers and technicians looking to enhance their system’s performance and reliability.
