Pepperl + Fuchs PVM58I-032AGR0BN-1213 Encoder

Detection type:Photoelectric sampling

Device type:Multiturn absolute encoder

Operating voltage:4.5…30 V DC (SSI, SSI + RS422); 10…30 V DC (SSI + Push/Pull)

Output code:Gray code, binary code

Connector:Type 9416 (M23), 12-pin; Type 9416L (M23), 12-pin

Pulses:1024, 2048, 4096

Mass:Approx. 460 g (combination 1); Approx. 800 g (combination 2)

    The PVM58I-032AGR0BN-1213 encoder is engineered for industrial precision, featuring a robust and compact design suitable for a wide range of applications. It is equipped with advanced photoelectric sampling technology that ensures accurate measurement under varying conditions.

    This encoder is part of the P+F line of absolute encoders, renowned for their reliability and durability in harsh industrial environments. Its multiturn design allows for continuous and precise position tracking without losing calibration over time.

    With support for different power ranges (DC 4.5 to 30 V for SSI, SSI+RS422; 10 to 30 V for SSI+Push/Pull), this encoder is versatile and can be integrated into various control systems. The output codes are available in Gray and binary formats, providing flexibility in data interpretation.

    Equipped with a type 9416 or 9416L connector, this encoder offers a 12-pin connection for easy integration into machinery and automation systems. The choice between two mass combinations ensures a balance between size and weight according to specific application requirements.

    Ideal for applications requiring high-resolution measurement and robust performance, the PVM58I-032AGR0BN-1213 encoder is a reliable choice for enhancing accuracy and efficiency in industrial control systems.
