Operating Voltage:24V DC
Rated Current:10A
Protection Class:IP20
Operating Temperature Range:-25°C to +60°C
Relay Type:Solid State
Switching Capacity:Up to 250V AC/3A
Mounting Method:Panel Mount
Input Delay Time:Adjustable, typically 0.1s to 1s
Response Time:Less than 1ms
Protection Characteristics:Thermal overload, short-circuit, and phase loss
The ABB 193-EC2DD Solid State Overload Relay is engineered to provide unparalleled protection against overcurrent events in industrial settings. Its compact design ensures seamless integration into various control systems without compromising performance.
Featuring a solid state construction, this relay delivers high reliability and minimal maintenance requirements compared to traditional mechanical relays. It is capable of handling a current rating of up to 25A, making it suitable for a wide range of industrial applications.
Designed with an advanced thermal management system, the 193-EC2DD ensures consistent and reliable operation even under varying environmental conditions. Its robust insulation resistance guarantees electrical safety and prevents potential hazards in the workplace.
Equipped with a single-pole double-throw (SPDT) contact configuration, this relay allows for versatile switching capabilities. The contact rating of 250VAC, 5A provides ample capacity for controlling power loads without exceeding safe limits.
Operational temperature range from -25°C to +55°C ensures the relay can withstand extreme conditions encountered in industrial environments. Its compact size (70mm x 70mm x 40mm) allows for efficient space utilization and easy installation within control panels.
