Spectrum Controls 1746SC-INI4VI Analog Input Module – High-Resolution Input Solution

Number of Channels:4

Input Range (V):-10 to +10 VDC

Absolute Input Voltage (V):+/-7.5 VDC or 7.5 VAC RMS

Input Range (mA):-30 to +30 mA

Common Mode Voltage Range (V):-20 to +20 V

Isolation Voltage (V):500 VDC

Backplane Current Draw (mA):35 at 5V, 85 at 24V

Operating Temperature (°C):-40 to +85

Storage Temperature (°C):-40 to +105

Dimensions (mm):122 x 97 x 137

Weight (kg):0.32

    The Spectrum Controls 1746SC-INI4VI Analog Input Module is a robust solution for industrial environments, engineered to withstand harsh conditions while providing accurate and consistent readings.

    Featuring four high-resolution channels, this module excels in capturing precise analog signals from a wide range of sensors, making it ideal for applications requiring high accuracy and reliability.

    With its ability to operate within an extensive temperature range of -40°C to +70°C, the 1746SC-INI4VI ensures continuous performance in varying environmental conditions, enhancing system stability.

    The module boasts a superior isolation voltage rating of 500VDC, protecting both the system and operators from electrical hazards while maintaining the integrity of signal transmission.

    Designed with efficiency in mind, the low power consumption of ≤1.5W reduces operational costs and ensures minimal impact on the overall energy management of the industrial setup.
