Motor Type:Servo Motor
Model:SGMAV-A5ANA-YR23
Nominal Power:1.5kW
Maximal Torque:30Nm
Speed Range:500 – 3000 rpm
Operating Voltage:230V
Enclosure Type:IP23
Motor Frame Size:100mm x 100mm x 240mm
Control Interface:4-20mA
Motor Weight:5kg
The Yaskawa SGMAV-A5ANA-YR23 servo motor is a cornerstone of precision motion control in industrial automation, featuring a compact, flat design that maximizes space utilization on machinery.
With a rated speed of 3,000 RPM and a maximum speed reaching up to 5,000 RPM, this motor is engineered for applications demanding high-speed, accurate positioning.
Equipped with an incremental encoder, it offers precise feedback for enhanced control and repeatability in manufacturing processes.
Capable of delivering a constant torque of 1.5 Nm and a peak torque of 4.5 Nm, the motor ensures robust performance even under varying loads.
The inclusion of a brake system ensures smooth operation and safety, preventing unwanted movement when the power is off.
Certified to IP67 standards, this motor is protected against dust ingress and can withstand water jets from any direction, making it suitable for harsh industrial environments.
Compliant with international safety standards including UL, CE, and cUL Recognized, it guarantees reliability and safety in global applications.
