Model Type:ControlLogix Bridge Module
Manufacturer:Allen Bradley
Model Number:1756-CNBD
Number of Channels:Redundant 2 Channels
Current Rating:Drawn: 970 mA at 5.1 VDC, 1.7 mA at 24 VDC
Isolation:30 V (Continuous)
Basic Insulation Type:ControlNet A/B to Backplane, ControlNet A to ControlNet B
No Isolation Between NAP Or USB and Backplane:Not applicable
Enclosure Type:Open Type
RFI Suppression:Radiated: 10 V/M with 1 KHz sine-wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% pulse 100% AM at 900 MHz, 3 V/M with 1 KHz sine-wave 80% AM from 2000 – 2700 MHz
Conducted EMI:10 VRMS with 1 KHz sine-wave 80% AM from 150 kHz – 80 MHz
The Allen Bradley AB 1756-CNBD ControlLogix Bridge Module is engineered for enhanced network interoperability, enabling a smooth connection between ControlLogix platforms and diverse industrial protocols.
With its redundant 2-channel design, this module ensures high reliability and system availability, critical for mission-critical operations.
Capable of managing both current and voltage inputs, it supports a wide range of applications within manufacturing, processing, and automation environments.
Equipped with advanced RFI suppression technology, the module safeguards against electromagnetic interference, ensuring stable communications under challenging industrial conditions.
Designed for an open type enclosure, it provides a compact solution for space-constrained industrial settings without compromising on performance.
Serving as a pivotal link between ControlLogix systems and external networks, this module optimizes data exchange and system scalability, contributing to streamlined operation management.
